1. Communication Cable – G3 / Modular Controller / Data Station Plus to Mitsubishi FX Series
cblmit01_0.docx
Cable Details
- Cable Part Number: CBLMIT01
- Length: 10 feet
- Application: G3 / Modular Controller / Data Station Plus to Mitsubishi FX Series (RS‑485)
Connector Information
- Controller Side: RJ45
- PLC Side: DB25 Male
Connector Pinout
| FROM RLC UNIT | Signal Name | RJ45 Pin | DB25 Male Pin |
|---|---|---|---|
| 1 | TxB | 1 | 2 |
| 2 | TxA | 2 | 15 |
| 3 | RxA | 3 | 16 |
| 4 | RxB | 4 | 3 |
| 5 | TxEN | 5 | — |
| 6 | COMM | 6 | 7 |
| 7 | TxB | 7 | — |
| 8 | TxA | 8 | — |
| — | — | — | 4, 8 |
| — | — | — | 12, 17 |
| — | — | — | 20, 21 |
Wiring Notes
- The table above denotes the pin names of the RS‑485 port.
- When connecting devices, the pin name at the RS‑485 port connects to the opposite pin name at the destination device.
- Listed DB25 pins without direct signal mapping are not connected.
RS‑485 Port Reference
| Connections | |||
| RLC UNIT | Name | CONNECTER PINOUT | |
| RJ45 | DB25 MALE | ||
| 1 | TxB | 1 | 2 |
| 2 | TxA | 2 | 15 |
| 3 | RxA | 3 | 16 |
| 4 | RxB | 4 | 3 |
| 5 | TxEN | 5 | - |
| 6 | COMM | 6 | 7 |
| 7 | TxB | 7 | - |
| 8 | TxA | 8 | - |
| - | - | - | 4, 8 |
| - | - | - | 12, 17 |
| - | - | - | 20, 21 |
