1. Communication Cable – G3 / Modular Controller / Data Station Plus to Generic RS‑232
cblgen01_3.docx
Cable Details
- Cable Part Number: CBLGEN01
- Length: 10 feet
- Application: G3 / Modular Controller / Data Station Plus to generic RS‑232 device
Connector Information
- From RLC Unit: RS‑232 port
- To Destination Device: Generic RS‑232
Wiring Notes
- The pin names listed refer to the RS‑232 port on the RLC unit.
- When wiring, each pin name on the RLC side is connected to the opposite pin name on the destination device, following standard RS‑232 cross‑connection rules.
Reference Images
